Stacking Type Lifepo4 Battery Packs 51.2V 5~75KWH
Product Parameter
| Electrical Characteristics | ||
| Nominal Voltage | 51.2V | |
| Nominal Capacity | 5~75KWH | |
| Mechanical Characteristics | ||
| Inverter size/weight | 602*403*139mm | |
| Battery size/weight | 602*403*200mm/55KG (single module） | |
| Base size/weight | 602*403*82mm/55KG | |
| Electrical Characteristics | ||
| Standard Charging Voltage | 58.4V | |
| Discharge Cut-off Voltage | 40V | |
| Recommended Charging Current | 100A/200A(Max) | |
| Max Discharge Current | 200A | |
| Hybrid grid inverter (optional) |
||
| Phase |
single-phase |
|
| Maximum output power |
3000-12000W(optional) |
|
| Recommended Charging Current |
110~120/230~240VAC |
|
| Rated grid frequency |
50HZ/60HZ |
|
| PV maximum input power |
7000W |
|
| MPPT voltage range |
60-150Vdc |
|
| Charge and discharge efficiency |
>98% |
|
| Operating Condition | ||
| Cycle Life |
+25℃ 0.2C 100%DOD＞3000 Times +25℃ 0.2C 80%DOD＞6000 Times |
|
| Display Type | LCD Screen Power Display | |
| Bluetooth/WIFI | Optional | |
| Communication Interface | RS485, RS232, CAN, Dry Contact | |
| Operating Temperature | -10~60℃ @60±25% humidity | |
| Storage Temperature | -5~45℃ @60±25% humidity | |
| Storage Duration | 6 months at 25℃ | |
| Safety standard | CE ISO9001,UN38.3,MSDS | |
| IP Degree | IP20 | |
Features:
- LiFePO4 battery, more stable and safe.
- Intelligent BMS equipped inside to maintain the battery always work at best condition .
- Max charge and discharge current as 200A which is specially designed for solar energy .
- With equalizer can balance each lithium cell voltage difference as small as 0.05V in a very short time.
- Within solar inverter Modbus-485 communication protocol. Excellent standby self-consumption as low as 4mA.
- Automatically output cut off after 30 days no charge and discharge to ensure security ,also can cut off output by manual operation
- The inverter and battery packs are stacked for simpler installation and grid assembly.
- Low self-discharge rate:<2% monthly
BMS Specification For Lithium Battery:
- Overcharge detection function
- Over discharge detection function
- Over current detection function
- Short detection function
- Balance function
- Temperature protection
Application:
- Solar/wind energy storage system
- UPS, backup power
- Telecommunication
- Medical equipment
